| Genset Brand | Enmaksan Generator | |
| Genset Model | EN220P | |
| Standby Power | kVA | 220 |
| Prime Power | kVA | 200 |
| Frequency | Hz | 50 |
| Voltage | V | 230/400 |
| Phase | 3 | |
| Fuel | Diesel | |
| Control Panel | Datakom 500 | |
| Country of Origin | Turkey |
| Engine Brand | PERKINS | |
| Engine Model | 1106A-70TAG4 | |
| Standby Power | kWm | 191.3 |
| Prime Power | kWm | 173.9 |
| Fuel Type | Diesel | |
| Number of Cylinders and Type | 6 – In Line | |
| Bore x Stroke | mm | 105×135 |
| Total Displacement | L | 7,1 |
| Aspiration | Turbocharged and air charge cooled | |
| Compression Ratio | 16:1 | |
| Rated Speed | rpm | 1500 |
| Injection Type and System | Direct injection | |
| Governor System | Mechanical | |
| Operating Voltage | Vdc | 12 |
| Cooling System | Water Cooled | |
| Air Filter Type | Dry Type |
| Maranello | M220 | |
| Stamford | UCI274H | |
| Leroy Somer | TAL A46 |
Dimensions Without Canopy and Weight |
||
| L x W x H | mm | 2800x1100x1700 |
| Weight | kg | TBA |
| Fuel Tank Capacity | kg | 370 |
Dimensions With Canopy and Weight |
||
| L x W x H | mm | 3500x1100x2200 |
| Weight | kg | 2220 |
| Fuel Tank Capacity | lt | 370 |
| Desibel | db(A) | 65-75 |
